Marble CNC Router QL-1218

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1468536

• Place of Origin:

  China
• Marble CNC Router QL-1218

  Details:
  1>imported linear square rails, dual four slider, loading capacity, smooth operation and high knife precision.
  2> The entire machine seamless welded steel structure, rigid Haobu deformation, table back lining plate, the rigid strength, and machine loading capacity can be
  3>constant power spindle motor, cutting intensity, high efficiency.
  4>software compatible with Typ3/Artcam/Castmate / Wentai, and other CAD / CAM design software
  5>two-way tool cooling system, effectively raising tool life

  Capacity:
  1.X.Y working area1200*1800mm
  2.Z working area>120mm
  3.Table1440*3000mm
  4.operating speed8m/min
  5.carving speed6m/min
  6.Resolution0.01mm
  7.Repeat positioning accuracy0.05mm
  8.Feeding greatest height120mm
  9.CommandG code*.u00*.mmg*.plt
  10.Surroundings for softwarewindows98/2000/xp
  11.Power(exclude spindle)1500w
  13.Work voltageAC220V/50Hz
  14.Spindle power2.2KW
  15.Spindle rotating speed24000rpm/min
  16.Work ModeSteper
  Standard Configure:
  1)Steel construction lathe bed, Table-board mould,
  2) X Y rack driven,Z ball screw, circular guides in 3 axis.
  3)ASK bearing imported from Janpan, imported flat cable
  4)Spindle and Transducer2.2KW,
  5)Double-motor driving in Y axis,
  6)Ncstudio system, LeadShine Driver
  7) Max Speed: 10-12m/min
  8)Software: ARTCAM,TYPE3
  9) a set of cutters,20 pieces

  Appliable Fields:
  1, stone crafts, make relief, scrupture,big statue,pottery and porcelain decration,etc.
  2.advertising industry: large advertising signs, acrylic brands,tableets,calligraphy,3D characters,garden or wall acrylic cutting, forming system module, billboard
  3, die industry: sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
  4, others: large-scale relief sculpture, video carving,craft and gift, widely used in process industries gifts.
