Marble CNC Router QL-1212

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1425658

• Place of Origin:

  China
• Marble CNC Router QL-1212
  Details:
  1, Germany-High-precision ball screws Preload Consumers gap, movement to reduce gap to min.
  2, 4 imports Pai ball linear guides, self-lubricating block so that the direction of force equal to ensure mechanical precision and intensity.
  3, breakpoint memory, guaranteed in the accident (Duandao) or next day, under processing.
  4, a number of workpiece machining unique way to preserve the original point.
  5, gantry movement, strengthen the surface, sturdiness and durability, prolonged use of distortion, so that more precise positioning accuracy.

  Capacity:
  1X.Y working area1200*1200mm
  2Z working area>100mm
  3Table1300*1420mm
  4Max. Speed5m-6m/min
  5Max. working speed2m-3m/min
  6Max. feeding height110mm
  7Working delicacy0.005mm
  8Repositioning accuracy0.05mm
  9CommandG code*.u00*.mmg*.plt
  10Surroundings for softwarewindows98/2000/xp
  11Power (spindle excluded)400w
  13Working voltageAC220V/50Hz
  14Spindle power1.5kw
  15Spindle rotating speed0-24000rpm/min
  16Drive motorSteper

  Standard Configure:
  1)Steel construction lathe bed
  2)Table-board mould
  3)Circular/round guides in 3 axis
  4)Germany-double with 3 axis ball screw imported from Germany
  5)Ncstudio system
  6)Motor of water-cooling transducer 1.5KW
  7)LeadShine Driver.
  8)Software: ARTCAM,TYPE3
  9) a set of cutters,20 pieces
  10)6 pieces of fixing clamps
  11)imported flat cable
  12)ASK bearing imported from Janpan

  Appliable Fields:
  1, stone crafts, make relief, scrupture,big statue,pottery and porcelain decration,etc.
  2.advertising industry: large advertising signs, acrylic brands,tableets,calligraphy,3D characters,garden or wall decoration,logo, acrylic cutting, forming system module, billboard field,mould.
  3,others: large-scale relief sculpture, video carving,craft and gift, widely used for gifts.
